Li Polymer Battery Pack 502535 400mAh 3.7V battery for Electronic
Appliances
Li Polymer Battery Pack 502535 Description
The 3.7V 400mAh li polymer battery model 502535 is designed for
electronics that require a long storage life. With a capacity of
400mAh, this battery provides reliable power for various
applications, ensuring devices operate efficiently over extended
periods.
Its long storage life makes it ideal for electronics that are not
used frequently, allowing users to maintain performance without the
need for constant recharging. The lightweight and compact design
facilitates easy integration into small devices, such as wearables
and portable gadgets.
Utilizing advanced lithium polymer technology, the 502535 battery
delivers stable voltage output, which is essential for consistent
device performance. Enhanced safety features help prevent
overheating and leakage, ensuring safe operation. Overall, this
battery is an excellent choice for developers seeking a dependable
power source for electronics, especially those that benefit from
prolonged storage.
Li Polymer Battery Pack 502535 Parameters
| Description: 502535 3.7V 400mAh Lithium Polymer Battery |
| Battery Type | Lithium Polymer Battery | Material | LiCoO2/NCM |
| Model | 502535 | Nominal Voltage/Capacity | 3.7V/400mAh |
| Cell Weight | Approx 7.5g | Color&Shape | Silver, Prismatic |
| Battrey Cell Dimension | MAX 5.0(T)x25.5(W)x35.5(L)mm | Battery Pack Dimension | MAX 5.0(T)x25.5(W)x37.5(L)mm |
| Cycle Life | ≥ 500 times | Warranty | 1 Year |
| Charge Info | Charge Voltage : 4.2V |
| Standard Charge Current : 80mA/0.2C |
| Max Charge Current: 400mA/1.0C(Customized) |
| Discharge Info | Discharge Cut-off Voltage : 3.0V |
| Standard Discharge Current : 80mA/0.2C |
| Max Discharge Current : 400mA/1.0C(Customized) |
| Operating Temperature | Charge: 0℃~+45℃ |
| Discharge: -20℃~+60℃ |
 |
Li Polymer Battery Pack 502535 Features
• Low Weight: Extremely lightweight, perfect for applications where
weight is a critical factor.
• Overcharge Protection: Equipped with built-in overcharge
protection to safeguard the battery and the device it powers.
• Temperature Stability: Maintains stable performance across a wide
temperature range, suitable for diverse environmental conditions.
• Customizable Dimensions: Can be customized in terms of dimensions
to fit specific space constraints within electronic devices.
• Long Shelf Life: Demonstrates a long shelf life with minimal
self-discharge, ensuring extended storage capabilities.
• High Energy Efficiency: Provides high energy efficiency,
maximizing the battery's power output and longevity.
• Safety Certified: Complies with safety standards and
certifications to ensure reliable and safe operation.
Li Polymer Battery Pack 502535 Applications
Toys, Power Tools, Wireless Home Appliances, Camera, Consumer
Electronics, GPS, Drone, Neck Fan, Electric Bicycles/Scooters,
Bluetooth Earphone, Electric Wheelchairs, Beauty Instruments,
Headset, Solar Energy Storage Systems.
Precautions for Use
1. Charging: Use a charger designed for polymer lithium batteries.
Avoid overcharging.
2. Discharging: Prevent deep discharge by avoiding extremely low
voltage levels. Most polymer lithium batteries have built-in
protection circuits.
3. Temperature: Operate within the recommended temperature range
provided by the manufacturer. Avoid exposing to extreme
temperatures.
4. Physical Handling: Handle with care to avoid damage or leakage.
Avoid impacts, punctures, or bending.
5. Compatibility: Ensure compatibility with your device in terms of
voltage, capacity, and size.
6. Storage: Store in a cool, dry place away from direct sunlight.
Avoid storing at full charge or completely discharged.
7. Transportation: Comply with transportation regulations and
guidelines.
8. Disposal: Dispose of properly. Recycle at designated facilities
or follow local regulations.
After-sales Service:
1. After-sales warranty:
- According to the contract, we provide a certain warranty period
for the exported lithium polymer batteries.
- During the warranty period, if the product has quality problems
under normal use conditions, we will provide replacement or return
service according to the after-sales policy.
2. Product quality assurance:
- We guarantee that the exported lithium polymer batteries comply
with international quality standards and regulations, and undergo
strict quality control and testing to ensure their performance and
reliability.
- If you find product quality problems under normal use conditions,
please contact us within the contractual warranty period, we will
actively deal with it and provide solutions.
3. Problem solving:
- If you encounter any problems or have any complaints during the
after-sales service, please contact our customer service team in
time.
- We will be happy to provide you with support and actively seek
solutions to your problems to ensure your satisfaction and good
cooperative relationship.
Our Advantages
◆ Over 10 years of li-polymer battery manufacture & export
experience
◆ Professional R&D team supporting
◆ Excellent quality, advanced equipment and competitive prices
◆ Good package, cheap freight cost, faster delivery, best
after-sales service
◆ OEM / ODM are welcome, we can customize different size to meet
customer's requirements
◆ Long life cycle of charging & discharging
***Please contact us to get more detailed information and free
samples***
