3.8V 280mAh Lipo Battery 482030/ CE Approved High Voltage Li-ion
Polymer Battery
LITHIUM ION BATTERY GENERAL INFORMATION
Lithium ion batteries (Li-Ion polymer) are high energy density
battery that are widely used in from the electric equipment to
electronics devices market. Unemetech manufactures lithium ion
batteries and li-polymer batteries with mainly three type of
chemical raw materials for different applications. These three
types chemical materials are LiCoO2, NMC and LiFePO4 used for anode
electrode. commonly LiCoO2 batteries are used for portable consumer
electronics because of its highest energy density in three, like
smartphones, medial players, table PC, while NMC and LiFePO4
lithium ion batteries are used for applications that requires
rugged operating environment, long cycle life, high output current,
such as power tools, solar energy storage, UPS , E-bikes, etc.
High Voltage Polymer Lithium Battery Key Features
♦ Environmental Friendly Chemistry
♦ High Energy Density
♦ High Power Density
♦ Fast Charge Capability
♦ Excellent Cycle Life
♦ Can customize Dimension, Capacity, Discharge Current and more.
High Voltage Lipo Battery 482030 Data Sheet
| Description: 482030 3.8V 280mAh High Voltage Li-polymer Battery |
| Battery Type | High Voltage Li-Polymer Battery | Material | LiCoO2/NCM |
| Model | 482030 | Nominal Voltage/Capacity | 3.8V/280mAh |
| Cell Weight | Approx 6.0g | Color&Shape | Silver, Prismatic |
| Battrey Cell Dimension | MAX 4.8(T)x22.0(W)x28.0(L)mm | Battery Pack Dimension | MAX 4.8(T)x22.0(W)x30.0(L)mm |
| Cycle Life | ≥ 500 times | Warranty | 1 Year |
| Charge Info | Charge Voltage : 4.35V |
| Standard Charge Current : 56mA/0.2C |
| Max Charge Current: 280mA/1.0C(Customized) |
| Discharge Info | Discharge Cut-off Voltage : 3.0V |
| Standard Discharge Current : 56mA/0.2C |
| Max Discharge Current : 280mA/1.0C(Customized) |
| Operating Temperature | Charge: 0℃~+45℃ |
| Discharge: -20℃~+60℃ |
High Voltage Lipo Battery Applications
The size of lithium polymer battery can be customized. We have
advantage making special Li-Po battery such as extremely thin Li-Po
battery , curved battery, high temperature Li-Po battery, low
temperature Li-Po battery and special shape Li-Po battery (round)
Precautions for Use
1. Charging: Use a charger designed for polymer lithium batteries.
Avoid overcharging.
2. Discharging: Prevent deep discharge by avoiding extremely low
voltage levels. Most polymer lithium batteries have built-in
protection circuits.
3. Temperature: Operate within the recommended temperature range
provided by the manufacturer. Avoid exposing to extreme
temperatures.
4. Physical Handling: Handle with care to avoid damage or leakage.
Avoid impacts, punctures, or bending.
5. Compatibility: Ensure compatibility with your device in terms of
voltage, capacity, and size.
6. Storage: Store in a cool, dry place away from direct sunlight.
Avoid storing at full charge or completely discharged.
7. Transportation: Comply with transportation regulations and
guidelines.
8. Disposal: Dispose of properly. Recycle at designated facilities
or follow local regulations.
After-sales Service
1. After-sales warranty:
- According to the contract, we provide a certain warranty period
for the exported lithium polymer batteries.
- During the warranty period, if the product has quality problems
under normal use conditions, we will provide replacement or return
service according to the after-sales policy.
2. Product quality assurance:
- We guarantee that the exported lithium polymer batteries comply
with international quality standards and regulations, and undergo
strict quality control and testing to ensure their performance and
reliability.
- If you find product quality problems under normal use conditions,
please contact us within the contractual warranty period, we will
actively deal with it and provide solutions.
3. Problem solving:
- If you encounter any problems or have any complaints during the
after-sales service, please contact our customer service team in
time.
- We will be happy to provide you with support and actively seek
solutions to your problems to ensure your satisfaction and good
cooperative relationship.
Our Advantages
◆ Over 10 years of li-polymer battery manufacture & export
experience
◆ Professional R&D team supporting
◆ Excellent quality, advanced equipment and competitive prices
◆ Good package, cheap freight cost, faster delivery, best
after-sales service
◆ OEM / ODM are welcome, we can customize different size to meet
customer's requirements
◆ Long life cycle of charging & discharging
***Please contact us to get more detailed information and free
samples***
